INVERTER ONDA SINUSOIDALE PURA 12V/230V 1500W SMART-IN N-BUS IVT

SMART-INPURE with IVT function is a range of inverters with an integrated priority system (Priority Switch type). This special IVT function, via the two 230V input and output sockets, allows the management of the voltage coming from the inverter connected to the battery and from the external network. When the external network (grid) is connected to the system, it will have priority in order to preserve the battery; when it is disconnected, the inverter will power the 230V output socket and the entire system connected to it.
What is the IVT function
More and more often the inverter represents the only solution for powering the utilities in the vehicle, but their size and power (over 1000W) make them impractical to move according to needs. The IVT function is a priority system that allows the inverter to automatically power itself from the 230V network, when available, and return to using the battery when necessary. This function makes it possible to connect, in extreme safety, the inverter output to the vehicle's electrical circuit, so as to always have all the sockets powered, leaving the inverter conveniently installed near the service battery.

ADDITIONAL FEATURES:

Priority function
Relay change time from inverter to 230VAC external network = 20 ms
Relay change time from 230VAC to external network = 100 ms

SPB 1500-I

INPUT VOLTAGE 12V
CONTINUOUS POWER 1500W
PEAK POWER 4000W
OUTPUT VOLTAGE 230Vac
USB OUTPUTS 5V 2.1A

DIMENSIONS 365x270x108h
CABLES INCLUDED 25mm2 length 80cm
